China OEM Light Tower Uae - RPLT-6800 CE Standard Metro Spec Customizable Hydraulic Mobile Lighting Tower for Construction Site – Robust

RPLT-6800 mobile light tower Our RPLT-6800 main spec: This model fit with telescopic vertical mast, controlled by hydraulic system and could reached at 8 meter in maximum. Lighting tower could set up by one-man operation, and also for the lamps that means all of the operation could perform on the ground.  Control panel could read most data of machine, mast extension, and could adjust lamp tilt for 90°. Good for saving time, easy control and labour saving.Both Four 1000 Watt metal halide is the standard configuration for this model and could provide bright lighting for areas up to 7 acres.Beside it,we also offer 4*480w LED lamps for option.In this way,the light effects is the same and better for the people’s eyes when workers work under it.And the fuel consumption is reduce great so the refueling time will be much longer.The spiral wire looks neat when the mast goes up and down.We Use Pro E for design to minimize the dimension error and insure the delivery time.All of our lighting tower,our QC people will examine every details before shipment. MOBILE LIGHT TOWER RPLT-6800 SERIES
Engine Kubota D1105-BG Diesel
Engine Type  3 cylinders,in line,water cooled
Prime Power 6.7kW / 50Hz     8.4kW/60Hz
Engine Aspiration Natural
Alternator Stamford PI044F/4pole,Brushless,excitation
Voltage 120,220,230,240V
Insulation H
Fuel Tank Capicity(L) 100 L
Fuel Consumption 2.0 L/h
Maximum Working Hours 50
Control system GU3303 Digital controller
Engine Shutdown Protection Low oil press,over speed,over current,high temperature
  detection,low fuel level
Ayxiliary Sockets 2
Total Power Of Lamps 4x1000W or 4x1500W
Type Of Lamp Metal halide lamp
Housing Materials Galvanization Reflector Housing
Lumen 4*110,000
Lifetime Of Lamp 5000 hours
Working Temperature ≤85°C
Connection Protection Index IP54
Type 6-Sections Telescoping mast 8M
Total Height Top 8M
Rotation 360 degrees
Operate For Elevation Hydraulic
Tow Hitch Ring/ball hitch
Stabilier Supports 4*Manual 4*Hydraulic
Tire Size 13 inch
Brakes Manual
Dry/Net Weight 930/890 kg
Extended Dimension(LxWxH) 4500*1350*1700mm
Shipping Package Iron Pallet 2100*1300*2400mm
  Carton 520*520*400mm
Container Load(20GP/40HQ) 6/12 sets
Color White/Yellow/Optional
